Product name:
Electromagnetic Flowmeter
Product series:

RFMN

Product brand:
PE/PE
Product feature:
• Protection class: IP68 / Type 6P • Supports system integration via HART or Modbus RS485 • Flexible operation with mobile APP and optional display unit • Reliable measurement: high accuracy maintained even with zero upstream straight pipe length; zero pressure drop • Flexible engineering design: integral and remote transmitter configurations available • Improved plant availability: sensors comply with industry specifications • Convenient operation: direct touchscreen control via mobile devices • Fast & simple commissioning with guided preset and field configuration
Favorite
Compare
Measuring principle:
Based on Faraday's law of electromagnetic induction, induced voltage is generated when a conductor moves through a magnetic field. In electromagnetic flow measurement, flowing medium acts as a moving conductor. The induced voltage (Ue) is proportional to the medium flow velocity (v), and is transmitted to the amplifier via two measuring electrodes. Volumetric flow rate (Q) is calculated using the pipe cross-sectional area (A). A switched direct current with alternating polarity produces the DC magnetic field. Calculation Formulas • Induced voltage: Ue = B · L · v • Volumetric flow rate: Q = A · v
Product positioning:
Standard
Using scenario:
Water & wastewater, chemical and process industries
