8721

The measurement principle of Rosemount 8721 sanitary sensor is based on Faraday's law of electromagnetic induction. When the conductive process medium flows through the excitation magnetic field inside the sensor, it will cut the magnetic field lines and generate an induced electromotive force in a direction perpendicular to the magnetic field and the flow direction. The magnitude of this electromotive force is directly proportional to the fluid flow rate. After a pair of measuring electrodes on the sensor tube wall detect the voltage signal, the accompanying transmitter converts it into a linear electrical signal proportional to the volumetric flow rate, thereby achieving flow measurement.

+1 Images Rosemount™ 8721 Hygienic Magnetic Flow Meter Sensors The Rosemount 8721 Hygienic Magnetic Flow Meter delivers safe, reliable performance for food, beverage, and life sciences applications with FDA‑approved materials, 3A‑compliant design, and sanitary connections for easy maintenance and inspection. The Rosemount 8721 Hygienic Magnetic Flow Meter Sensor uses an all-welded meter body that is specifically designed for food, beverage and life science applications that demand safe, hygienic and reliable performance. All contact surfaces are constructed of FDA-approved materials designed in accordance with 3A standards. Additionally, the 8721 is available with a variety of sanitary process connections with easily accessed process gaskets to facilitate efficient inspection and maintenance.
