FMR63B 80 GHz Radar Level Transmitter (Hygienic Design) - Processelite
*Picture for reference only !
FMR63B 80 GHz Radar Level Transmitter (Hygienic Design) - Processelite
Product name:
80 GHz Radar Level Transmitter (Hygienic Design)
Product series:

FMR63B

Product brand:
E+H/Endress+Hauser
Product feature:
• Complete hygienic design with EHEDG, 3-A and ASME BPE certifications, meeting the highest compliance requirements of the food, beverage and life sciences industries • 80 GHz high-frequency radar with extremely narrow beam angle and excellent focusing, measuring accuracy up to ±1 mm and maximum measuring range of 80 m • Built-in operating wizards guide users easily through commissioning, proof testing and verification, making operation extremely simple • Heartbeat Technology enables online verification of the radar's measuring accuracy and diagnostics during operation without interrupting the process, increasing productivity • Supports digital communication such as HART, PROFINET and Ethernet-APL for easy integration into asset management systems; the display backlight changes from green to red to immediately indicate errors
Porduct tag:
Food , Life science
Favorite
Compare
Measuring principle:
The FMR63B operates on the Frequency Modulated Continuous Wave (FMCW) principle. The antenna emits an 80 GHz microwave signal with a linearly varying frequency. The signal is reflected off the surface of the medium and received by the antenna. The frequency difference between the transmitted and received signals is proportional to the distance to the medium surface, enabling the level to be calculated with high precision. The 80 GHz high-frequency signal features an extremely narrow beam angle with excellent focusing performance and strong immunity to interference, enabling continuous non-contact level measurement.
Product positioning:
Using scenario:
The FMR63B is a member of the new generation of 80 GHz radar level transmitters. Thanks to its complete hygienic design, it is suitable for continuous non-contact level measurement in hygienic applications such as food & beverage and life sciences. Measuring accuracy ±1 mm, maximum measuring range 80 m, process temperature -40…+200 °C, process pressure vacuum…25 bar, main wetted parts PEEK or PTFE. Suitable for vessels with internal fittings (high beam focusing and strong anti-interference). Process connections support M24 adapters and hygienic connections, with optional 5-point or 10-point linearity protocol. Built-in operating wizards and Heartbeat Technology make commissioning simple, and the measuring accuracy can be verified during operation.
