OPTIFLEX 7200

Product brand:

Krohne/Krohne

Product feature:

Guided radar (TDR) level transmitter for advanced liquid applications; Continuous level and interface measurement in process or storage tanks, reactors and pressure vessels; Extensive choice of probes for harsh process conditions; Measuring range: 0.3…60 m / 1…197 ft; -50…+250°C / -58…+482°F; -1…100 barg / -14.5…1450 psig; OPTIFLEX 7200 C – Compact version with Ø42 mm / 1.65" coaxial probe and HT extension

Favorite

Compare

Configure

Measuring principle:

Guided wave radar level measurement

Product positioning:

Using scenario:

The OPTIFLEX 7200 is a 2-wire guided radar level transmitter based on the Time Domain Reflectometry (TDR) technology. With its large choice of probe types and materials, this level transmitter is the high-end guided radar for level and interface measurement in the chemical or oil and gas industries. It is suitable for storage or process tanks up to 60 m / 196.85 ft, containing all kind of liquids – from hydrocarbons like slop oil or benzene to solvents and acids to cooling water or condensate.
