OPTIWAVE 6400

Product brand:

Krohne/Krohne

Product feature:

• 2-wire 80 GHz FMCW radar level transmitter, high accuracy (±1 mm) • Measuring range 0-30 m • 4-20 mA HART 7 / 4-wire Modbus RTU optional • Custody transfer: MI-005 / MI-002, OIML R117-1 • WHG overfill protection, NAMUR NE 107, SIL 2 • PEEK Lens DN40/DN70 high accuracy antenna • KROHNE standard 3-year warranty

Favorite

Compare

Configure

Measuring principle:

The OPTIWAVE 6400 is a 2-wire 80 GHz radar level transmitter for high accuracy (±1 mm laboratory grade) level metering applications with liquids and granulates. Measuring range 0-30 m, process temperature -25 to +80°C, process pressure -1 to 40 bar. 4-wire Modbus RTU optional. Suitable for custody transfer (MI-005/MI-002), high accuracy inventory, filling, dynamic metering applications.

Product positioning:

High accuracy liquid and granulate level metering

Using scenario:

• Filling and dispensing system precision metering • Tank inventory management • Reactor process control • Oil tanks (high accuracy, custody transfer) • High-pressure vessels (up to 40 bar)
