OPTIWAVE 1540

Product brand:

Krohne/Krohne

Product feature:

• 2-wire 80 GHz FMCW radar level transmitter, high accuracy (±2 mm / ±0.08" standard, ±1 mm lab grade optional) • For liquids, granulates, bulk solids and mixed media with precise level measurement • Measuring range 0-30 m, process temperature -25...+80°C (standard) / -40...+150°C (high temperature) • PEEK Lens DN40 / DN70 high accuracy antenna • 4-20 mA HART 7 output, optional 4-wire Modbus RTU • IP66/IP68 ingress protection, Bluetooth + OPTICHECK Level Mobile app • Approvals: ATEX II 1G Ex ia IIC T6 Ga, IECEx, NEPSI, FM, cCS Aus • Custody transfer: MI-005 / MI-002 (tank gauging), OIML R117-1 (dynamic measurement) • WHG overfill protection, NAMUR NE 107 • SIL 2 capable, KROHNE standard 3-year warranty

Favorite

Compare

Configure

Measuring principle:

The OPTIWAVE 1540 is a 2-wire 80 GHz radar (FMCW) level transmitter for high-accuracy applications with liquids, granulates and bulk solids. The device achieves ±2 mm (±0.08") standard accuracy (up to ±1 mm laboratory grade optional) using a flush-mounted PEEK Lens antenna. Measuring range 0-30 m, process temperature -25 to +80°C (high temperature version to +150°C), process pressure -1 to 40 bar. MI-005/MI-002/OIML R117-1 custody transfer certifications available for precision inventory and filling applications.

Product positioning:

High accuracy level metering applications

Using scenario:

Typical high accuracy applications for the OPTIWAVE 1540: • Filling and dispensing systems (filling tanks, batching tanks) • Tank inventory management • Reactor and mixing vessel process control • Custody transfer oil tanks (MI-005 / MI-002) • LPG / LNG cryogenic level measurement • High-pressure vessels (up to 40 bar) • High-temperature vessels (-40 to +150°C) • Precision dosing in chemical, oil & gas, pharmaceutical and food reactors
