OPTIWAVE 1520

Product brand:

Krohne/Krohne

Product feature:

• 2-wire 80 GHz FMCW radar level transmitter, non-contact continuous level measurement • For liquids, granulates (sand, small particles), and pressurised vessels up to 5 bar/72.5 psi • PVDF Lens antenna (DN40/1½"), flush-mounted, chemically resistant, insensitive to condensation • Narrow 8° beam angle for small and narrow tanks • Measuring range 0-10 m, process temperature -25 to +80°C, process pressure -1 to 5 bar • IP66/IP68 ingress protection (IP68-rated waterproof version available for heavy rainfall / flooding) • 4-20 mA HART 7 output, Bluetooth + OPTICHECK Level Mobile app for parameterisation • ±5 mm accuracy, TBM (Tank Bottom Management) for empty tank measurement • Hazardous area approvals: ATEX II 1G Ex ia IIC T6 Ga, IECEx, NEPSI, FM, cCS Aus • PAC Tware, HART DD, HART DTM provided free of charge with full functionality • 3-year warranty, maintenance-free concept

Favorite

Compare

Configure

Measuring principle:

The OPTIWAVE 1520 is a 2-wire 80 GHz radar (FMCW) level transmitter for basic applications with liquids and granulates. The device uses a flush-mounted PVDF Lens antenna, measures distance, level, volume and reflectivity of liquids and solids by emitting and receiving frequency-modulated continuous-wave radar signals. Operating in 80 GHz with an 8° beam angle, it measures 0-10 m. The compact and robust IP66/IP68 design is particularly suitable for small tanks, storage vessels, pumping stations and silos, providing non-contact level measurement in water/wastewater and general industrial applications.

Product positioning:

Basic liquid and granulate applications

Using scenario:

Typical applications for the OPTIWAVE 1520: • Extraction, transport, storage and distribution of water (springs, rivers, lakes, sea) • Level measurement in rainwater basins • Open-channel flow measurement • Level measurement in storage vessels, water basins, wastewater tanks, pumping stations • Floodwater alarm • Level measurement in plastic tanks (IBC containers) • Small silos for sand and other granulates • Remote monitoring of pumping stations (suitable for unattended outdoor installations)
