OPTIWAVE 5400

Product brand:

Krohne/Krohne

Product feature:

Radar level transmitter for liquids in standard process applications; Continuous, non-contact level measurement in closed tanks or in the open air; 24 GHz radar, Horn or Drop antennas; Measuring range: 0…100 m / 328 ft; -50…+130°C / -58…+266°F; -1…16 barg / -14.5…232 psig; Configure

Favorite

Compare

Configure

Measuring principle:

Radar level measurement

Product positioning:

Using scenario:

The OPTIWAVE 5400 is a 2-wire 24 GHz radar (FMCW) level transmitter for liquids in basic process applications. It is particularly designed for continuous, non-contact level measurement in the chemical, petrochemical, power as well as oil and gas industry. It can be equipped with a PP Drop antenna for condensing atmospheres and corrosive media but features also Metallic Horn antennas. Due to its high dynamic range, the 24 GHz radar can measure distances up to 100 m / 328 ft.
