OPTIWAVE 3500

Product brand:

Krohne/Krohne

Product feature:

Radar level transmitter for liquids with hygienic requirements; Continuous, non-contact level measurement in small and narrow vessels, small storage tanks and agitated tanks; 80 GHz radar, flush-mounted Lens antenna; Measuring range: 0…50 m / 164 ft; -40…+150°C / +302°F; -1…25 barg / -14.5…362 psig; Configure

Favorite

Compare

Configure

Measuring principle:

Radar level measurement

Product positioning:

Using scenario:

The OPTIWAVE 3500 is a 2-wire 80 GHz radar (FMCW) level transmitter for liquids in hygienic applications. It is designed for continuous, non-contact level measurement in the food and beverage as well as pharmaceutical industry. The device features a flush-mounted PEEK Lens antenna with a small beam angle and dead zone for precise measurement even in small and narrow tanks with agitators. It is equally suited for use on larger tanks, measuring distances of up to 50 m / 164 ft.
