All >> Flow Measurement >> Electromagnetic Flowmeter
*Picture for reference only !
Product name:
Electromagnetic Flowmeter
Product series:

5W3B

Product brand:
E+H/Endress+Hauser
Product feature:
• International drinking water approvals • Protection class IP68 (Type 6P housing) • Custody transfer measurement according to MI-001/OIML R49 • Compact dual-compartment housing with up to 3 inputs/outputs • Backlit display, touch key control and WLAN access • Separate display unit available • High-accuracy, reliable measurement, no straight-run requirements, no pressure loss • Flexible design: sensor with fixed or loose flange process connection • Suitability: corrosion protection for underground or underwater installation per EN ISO 12944
Favorite
Compare
Measuring principle:
According to Faraday's law of electromagnetic induction, a conductor moving in a magnetic field generates an induced voltage. In electromagnetic flow measurement, the flowing medium acts as the moving conductor. The induced voltage (Ue) is proportional to the medium flow velocity (v) and is applied to the amplifier through two measuring electrodes. The volumetric flow rate (Q) is calculated based on the pipe cross-sectional area (A). An alternating polarity switched DC current generates a direct current (DC) magnetic field. Calculation formulas • Induced voltage: Ue = B · L · v • Volumetric flow rate: Q = A · v
Product positioning:
Water and wastewater applications
Using scenario:
Promag W 300 high-accuracy electromagnetic flowmeter for water and wastewater measurement, reliable operation in hazardous areas and demanding conditions. The compact transmitter offers high flexibility in operation and system integration: operation and wiring on the same side of the transmitter, optional remote display, freely configurable I/O functions and diverse system bus integration. Heartbeat technology ensures reliable measurement and compliant verification. • Bidirectional measuring principle completely unaffected by pressure, density, temperature and viscosity • Specifically designed for industrial or municipal water and wastewater measurement
