Product name:
Electromagnetic Flowmeter
Product series:

5E1B

Product brand:
E+H/Endress+Hauser
Product feature:
• Nominal diameter: max. DN600 (24") • Zone 2 explosion‑proof certification • PTFE liner • Robust, ultra‑compact integrated transmitter housing • Optional on‑site display unit • Economical sensor: ideal solution for basic requirements • Energy‑saving flow measurement: no pressure loss caused by restriction of pipe cross‑section • Maintenance‑free: no moving parts • Compact transmitter: full functionality for confined spaces • Time‑saving on‑site operation without additional software and hardware: integrated web server • Self‑monitoring and self‑verification: Heartbeat Technology
Favorite
Compare
Measuring principle:
Based on Faraday’s law of electromagnetic induction, an induced voltage is generated when a conductor moves in a magnetic field. In the electromagnetic measuring principle, the flowing medium acts as a moving conductor. The induced voltage (Ue) is proportional to the medium flow velocity (v), and is fed to an amplifier via two measuring electrodes. The volumetric flow rate (Q) is calculated from the pipe cross‑sectional area (A). A switched direct current with alternating polarity generates the direct‑current (DC) magnetic field. Calculation formulas • Induced voltage: Ue = B · L · v • Volumetric flow rate: Q = A · v
Product positioning:
Chemical & Process industries & Economical
Using scenario:
Promag E is the standard electromagnetic flow sensor for the chemical industry, delivering cost‑effective solutions for chemical customers. Fitted with a compact transmitter housing, it provides full functionality in limited space. Designed for space‑constrained applications, Promag E 100 is an ideal choice for system integrators, skid builders and equipment manufacturers. Promag E is a reliable, economical sensor for conductive liquids, suited for a wide range of standard applications in the chemical industry. Equipped with an ultra‑compact, fully‑featured transmitter, Promag E 100 enables seamless system integration, making it the preferred option for skid builders, equipment manufacturers and system integrators. Heartbeat Technology consistently ensures compliance and process safety. • Bi‑directional measuring principle independent of pressure, density, temperature and viscosity • Fully suitable for standard applications in chemical and process industries
