All >> Flow Measurement >> Electromagnetic Flowmeter
*Picture for reference only !
Product name:
Electromagnetic Flowmeter
Product series:

DTI200

Product brand:
E+H/Endress+Hauser
Product feature:
• Compact construction design saves installation space • Nominal diameter: DN15…2000 (1/2…80") • Suitable for installation in steel or plastic pipes • Switch point setting via rotary switch • Current output and relay output • ATEX, FM and CSA approvals • High plant availability with reliable flow information • Energy‑saving flow measurement: no throttling components, zero pressure loss • Maintenance‑free: no moving parts • Process safety: built‑in self‑monitoring for reliable detection even under empty pipe conditions • Product safety: integrated test function to verify proper operation of electronic components • Easy operation: full‑scale value can be set electronically
Favorite
Compare
Measuring principle:
Based on Faraday's law of electromagnetic induction, an induced voltage is generated when a conductor moves in a magnetic field. In the electromagnetic measuring principle, the flowing medium acts as a moving conductor. The induced voltage (Ue) is proportional to the medium flow velocity (v), which is transmitted to the amplifier via two measuring electrodes. The volumetric flow rate (Q) is calculated based on the pipe cross‑sectional area (A). A switched direct current with alternating polarity generates the DC magnetic field. Calculation formulas • Induced voltage: Ue = B · L · v • Volumetric flow rate: Q = A · v
Product positioning:
Compact Electromagnetic Flow Switch
Using scenario:
The economical integral flow limit switch Magphant is suitable for water applications in utilities. It features high repeatability for reliable flow monitoring and easy operation, helping ensure process and plant safety. • Bidirectional measuring principle, independent of pressure, density, temperature and viscosity • Widely used for various water applications in utilities
