All >> Flow Measurement >> Ultrasonic Flowmeter
*Picture for reference only !
Product name:
Ultrasonic Flowmeter
Product series:

93T

Product brand:
E+H/Endress+Hauser
Product feature:
• Automatic frequency scanning for optimum performance • Fast and secure installation with specially designed mounting kit • Zero leakage risk: measurement is performed externally on the pipe • High process transparency with diagnostic functions • Temporary monitoring of measuring points: portable flowmeter equipped with rechargeable battery and current output • Verification of other flow‑measuring devices: built‑in data logger and current input • Automatic data recovery function
Favorite
Compare
Measuring principle:
The measuring system operates on the transit‑time principle. Acoustic signals (ultrasonic waves) are transmitted between two sensors. Bi‑directional signal transmission is supported, meaning each sensor can send and receive acoustic waves. The propagation speed of sound increases when travelling with the flow and decreases when travelling against the flow, resulting in a transit‑time difference. This transit‑time difference is proportional to the flow velocity of the medium. The measuring system calculates the volumetric flow rate of the medium using the measured transit‑time difference and the pipe cross‑sectional area. In addition to the transit‑time difference, the sound velocity of the medium can be measured simultaneously. This extra measured variable enables differentiation between different media or monitoring of medium quality.
Product positioning:
Portable & Clamp‑on
Using scenario:
The portable ultrasonic flowmeter Prosonic Flow 93T is specially designed for temporary monitoring and test measurements using clamp‑on sensors. It operates independently on battery power with no external power supply required. The Prosonic Flow 93T is an ideal tool for verification measurements on existing flow measuring points.
