COS22E

In amperometric dissolved oxygen measurement, oxygen molecules diffuse through the membrane and are reduced to hydroxide ions (OH⁻) at the working electrode. At the counter electrode, silver is oxidized to silver ions (Ag⁺), forming a silver halide layer. The release of electrons at the working electrode and their consumption at the counter electrode generate an electrical current. Under constant operating conditions, this current is proportional to the oxygen concentration in the process medium. The current is converted by the transmitter and displayed as oxygen concentration in mg/L, µg/L, ppm, ppb, Vol%, ppmVol, or as the raw value in nA. The measurement can also be displayed as oxygen saturation (%SAT) or oxygen partial pressure (hPa).

Standard

The Memosens COS22E fully complies with FDA and USP requirements and is designed for sterile and hygienic applications. It features low maintenance requirements, excellent long-term stability, and high resistance to frequent sterilization processes. The sensor is suitable for trace oxygen measurement, helping protect products, processes, and equipment from oxygen-related contamination or interference. Featuring Memosens 2.0 digital technology, the COS22E provides extended data storage for calibration and process parameters, providing an ideal foundation for predictive maintenance and IIoT applications. The Oxymax COS22E is designed for dissolved oxygen measurement in critical processes across multiple industries, particularly in life sciences and biotechnology applications.
