CCS51

Based on the amperometric measurement principle, the sensor uses hypochlorous acid (HOCl) to measure the residual chlorine concentration. Hypochlorous acid (HOCl) in the process medium diffuses through the sensor membrane and is reduced to chloride ions (Cl⁻) at the gold cathode. At the silver anode, silver is oxidized to silver chloride (AgCl). The gold cathode releases electrons while the silver anode accepts electrons, forming an electrical current circuit. Under constant operating conditions, the circuit current is directly proportional to the residual chlorine concentration in the process medium. The concentration of hypochlorous acid depends on the pH value. An auxiliary pH measurement is used to compensate for this effect. The transmitter calculates the chlorine concentration from the amperometric current signal and displays the measured value in mg/L (ppm).

Standard

The CCS51 residual chlorine sensor is robust, durable, and low-maintenance. It provides highly accurate and long-term stable measurements in drinking water, pool water, and process water, ensuring reliable monitoring of disinfection processes even at low flow rates. The analog residual chlorine sensor features a fast response time, ensuring efficient process control and enhanced process safety. The CCS51 analog residual chlorine sensor provides continuous measurement values at the measuring point. The Memosens CCS51D residual chlorine sensor meets the requirements of skid manufacturers and end users, providing reliable measurement in the following applications: • Drinking water • Process water • Utilities • Pool water
