Product name:
Absolute and gauge pressure Cerabar PMP55
Product series:

PMP55

Product brand:
E+H/Endress+Hauser
Product feature:
• Large variety of process connections and diaphragm materials • New TempC diaphragm minimizes the effects of ambient and process temperature fluctuations • Easy menu-guided commissioning via on-site display, 4 to 20 mA with HART, PROFIBUS PA, and FOUNDATION Fieldbus • Process pressure monitoring up to SIL2, certified according to IEC 61508 and IEC 61511 • Modular design concept for easy replacement of display modules or electronics • Seamless and independent system integration (HART/PA/FF)
Favorite
Compare
Measuring principle:
Pressure transmitter measurement is primarily based on the deformation characteristics of the diaphragm. When the process pressure changes, the fill fluid transfers the pressure to the Wheatstone resistance bridge, converting the deformation of the sensing element into an electrical signal. The electrical signal is then transmitted through wires to the amplifier for signal amplification and processing, and finally converted into a standard output signal (typically 4–20 mA) for communication with the control system.
Product positioning:
Economical
Using scenario:
The Cerabar PMP55 digital pressure transmitter features a metal diaphragm seal and is mainly designed for process industries and hygienic applications. It is suitable for measuring the pressure of liquids, as well as level, volume, and mass measurements. The PMP55 is specially developed for high-pressure and extreme high-temperature applications, with a maximum operating temperature of up to 400 °C (-94 to 750 °F). With adjustable measuring ranges and fast setup functions, it helps reduce commissioning costs and time. Compliant with IEC 61508 and IEC 61511 standards, it meets SIL2 functional safety requirements.
