Radar Level Transmitter

E+H/Endress+Hauser

• Specially suited for compact process connections; PTFE sensor suitable for corrosive chemical media • Process connections: 1½" threaded or flanged • Temperature range: -40 to +150°C (-40 to +302°F) • Pressure range: -1 to +40 bar (-14.5 to +580 psi) • Maximum measuring range: 20 m (66 ft) • Accuracy: ±6 mm • C-band: 6 GHz • International explosion protection, WHG overfill prevention, SIL, and 5-point linearity certificate • Reliable measurement even under changing medium and process conditions • HistoROM integrated data storage for fast commissioning, maintenance, and diagnostics • High measurement reliability with Multi-Echo Tracking, even with vessel obstructions • IEC 61508-compliant hardware and software; SIL2 for single devices and up to SIL3 with homogeneous redundancy • Heartbeat Technology for safe and efficient plant operation throughout the entire lifecycle • Seamless integration into control and asset management systems with intuitive menu-guided operation • SIL and WHG certified proof testing to save time and costs
