*Picture for reference only !
*Picture for reference only !
*Picture for reference only !
*Picture for reference only !
Product name:
Micropilot FMR67B – 80 GHz radar sensor
Product series:

FMR67B

Product brand:
E+H/Endress+Hauser
Product feature:
• Process connections: Flanged • Temperature range: -40 to +450°C (-40 to +842°F) • Pressure range: -1 to +160 bar (-14.5 to +2,320.6 psi) • Maximum measuring range: 125 m (410 ft) • Accuracy: ±3 mm (0.12 in) • W-band: 80 GHz • International explosion protection, SIL, and 5- or 10-point factory calibration certificates • Intuitive operation with wizards for easy commissioning and verification • Heartbeat Technology for process monitoring, verification, and diagnostics during operation • IEC 61508-compliant development for enhanced safety • Digital communication for easy integration into asset management systems • Reliable measurement with a narrow beam angle and intelligent signal evaluation, even in vessels with internal obstructions
Favorite
Compare
Measuring principle:
Radar measurement is based on the frequency-modulated continuous wave (FMCW) principle. The antenna transmits a continuously frequency-swept signal, and the reflected signal is mixed with the reference signal to generate a beat frequency. The instrument determines the time of flight from the frequency difference and calculates the distance to the medium surface, enabling accurate level measurement. FMCW technology offers strong interference resistance and high measurement accuracy, but at a relatively higher cost.
Product positioning:
Standard
Using scenario:
Micropilot FMR67B is a next-generation 80 GHz radar level transmitter for continuous, non-contact level measurement of solids under demanding conditions, including high temperatures. Integrated wizards simplify commissioning, functional safety, and verification testing. Its narrow beam angle is ideal for measurement in narrow silos. Heartbeat Technology enables continuous self-verification and monitoring, helping detect abnormal conditions early, improve process safety, and increase productivity.
