Micropilot

E+H/Endress+Hauser

• Radar for continuous level and flow measurement (in open channels or weirs via linearization tables), suitable for storage tanks, open basins, pumping stations, and sewage lift stations • Process connections: Threaded, flanged • Process temperature: -40 to +80°C (-40 to +176°F) • Process pressure: -1 to +3 bar (-14.5 to +43 psi) • Maximum measuring range: Liquids 20 m (66 ft), solids 10 m (33 ft) • Accuracy: Liquids ±2 mm (0.08"), solids ±5 mm (0.2") • Operating frequency: 26 GHz • International explosion protection certificates • Non-contact radar with commissioning via HART, or wireless commissioning using a Bluetooth® app or remote display unit • Ultra-compact radar with integrated radar chip design, ideal for space-constrained applications • Cost-effective radar solution • Particularly suitable for water and wastewater applications, as well as utility applications across various industries (IP66, IP68 / NEMA 4X, 6P) • Fully PVDF housing suitable for outdoor installation; sealed cable entries and fully encapsulated electronics provide reliable waterproof protection under harsh operating conditions • Simple setup with three key parameters to meet the requirements of most applications • Simple and secure wireless remote access via Bluetooth®, even in hazardous areas or confined spaces
