TTR35

A Resistance Temperature Detector (RTD) measures temperature based on the principle that the electrical resistance of a metal conductor changes with temperature. The basic principle is that when temperature changes, the lattice vibration of metal conductors such as platinum and copper changes, affecting electron movement and causing the electrical resistance value to vary accordingly. Taking the platinum resistance sensor Pt100 as an example, the standard resistance value is 100 Ω at 0 °C. The resistance increases by approximately 0.385 Ω for every 1 °C rise in temperature, showing a highly linear relationship within a defined temperature range. In practical measurement applications, a constant current source or bridge circuit converts resistance changes into electrical signals. Three-wire or four-wire connection technology is used to eliminate lead resistance errors, and the resistance value is converted into temperature according to internationally standardized resistance-temperature tables.

Standard

Modern process measurement technology requires solutions that provide high cost efficiency, space-saving design, reliable operation, easy installation, and simple commissioning. This hygienic temperature switch is specifically designed to meet the demanding requirements of the food and beverage and life science industries. It provides safe and reliable process temperature measurement and monitoring, with flexible output configurations including one or two switching outputs, or one switching output combined with a standard analog output. With a variety of hygienic process connection options, the device offers flexible installation solutions for a wide range of sanitary process applications.
