TR66

Resistance Temperature Detectors (RTDs) measure temperature relying on the characteristic that the resistance of metallic conductors changes with temperature. The core principle: as temperature varies, the amplitude of lattice vibration in metallic conductors such as platinum and copper changes, which creates different levels of impedance to electron movement and brings about corresponding resistance variation. Taking the Pt100 platinum RTD as an example, its nominal resistance is 100 Ω at 0 °C; resistance rises by approximately 0.385 Ω per 1 °C temperature increase, showing highly‑linear behaviour over a defined temperature range. For practical measurements, a constant‑current source or bridge circuit converts resistance variations into electrical signals. 3‑wire / 4‑wire connection eliminates lead‑wire errors, and resistance values are ultimately converted into temperature readings against international standard reference tables.

Standard Application

This thermometer is robust and durable, suited for harsh operating conditions and measurement scenarios with high safety requirements in chemical, oil & gas, energy and other industries. Its rugged thermowell and special materials can withstand harsh environments, corrosive media and high pressure. Optional transmitters support various common communication protocols for plug‑and‑play use. Compared with directly wired sensors, they offer improved measurement accuracy and reliability.
