TC65

Thermocouples feature a simple structure, high mechanical strength, and excellent durability. Temperature measurement is based on the Seebeck effect. Two different conductors are connected to form a closed circuit. When the temperatures at the two junctions are different, a small voltage difference is generated in the circuit. This voltage is known as the thermoelectric voltage or thermoelectromotive force (EMF). The magnitude of the thermoelectric voltage depends on the materials of the two conductors and the temperature difference between the measuring junction (the connection point of the two conductors) and the cold junction (the open end of the conductors). Therefore, thermocouples are typically used for temperature difference measurement. By knowing the cold junction temperature, or by measuring and compensating for it separately, the absolute temperature at the measuring junction can be accurately determined. Common thermocouple conductor combinations and their corresponding thermoelectric voltage/temperature characteristics are specified in IEC 60584 and ASTM E230/ANSI MC96.1 standards.

Standard

This rugged and durable thermocouple thermometer is designed for harsh operating conditions and safety-critical applications in industries such as chemical processing, oil and gas, and power generation. Optional head-mounted transmitters support various standard communication protocols and provide ready-to-install solutions, improving measurement accuracy and reliability compared with directly wired sensors. The sensor can be installed in direct contact with the process medium or used together with a spring-loaded thermowell, providing flexible installation options to meet different application requirements.
