YXC Magnetic-assisted Electric Contact Pressure Gauge - Processelite

*Picture for reference only !

Product name:

Magnetic-assisted Electric Contact Pressure Gauge

Product series:

YXC

Product brand:

PE/PE

Product feature:

- Stable performance - Easy installation - Low maintenance

Favorite

Compare

Configure

Measuring principle:

‌For electric contact pressure gauges, the Bourdon tube of the measuring system undergoes elastic deformation under the pressure of the measured medium. Such deformation is amplified by the gear transmission mechanism to drive the pointer to indicate the pressure reading. When the pointer reaches the preset value, the contacts close or open the circuit to switch the circuit on and off, realizing automatic control and alarm functions. An electric contact pressure gauge consists of a (magnetic-assisted) electric contact assembly, housing, gear transmission mechanism, indicating unit, pressure guiding system, terminal socket and adjustment device.

Product positioning:

Standard

Using scenario:

Electric contact pressure gauges are widely adopted in industrial sectors such as petroleum, chemical, metallurgy, power stations and machinery, as well as supporting electro-mechanical equipment, for measuring the pressure of various non-explosive fluid media. They are applicable to applications requiring local indication of process pressure together with threshold monitoring.

表盘直径：

60mm

100mm

150mm

耐振形式：

充油

安装方式：

径向

轴向带边

精度：

±1.6% o.f.s.

±2.5% o.f.s.

测量范围：

正压: 0~0.1Mpa

正压: 0~0.16Mpa

正压: 0~0.25Mpa

正压: 0~0.4Mpa

正压: 0~0.6Mpa

正压: 0~1Mpa

正压: 0~1.6Mpa

正压: 0~2.5Mpa

正压: 0~4Mpa

正压: 0~6Mpa

正压: 0~10Mpa

正压: 0~16Mpa

正压: 0~25Mpa

正压: 0~40Mpa

正压: 0~60Mpa

负压: -0.1~0Mpa

正负压: -0.1~0.06Mpa

正负压: -0.1~0.15Mpa

正负压: -0.1~0.3Mpa

正负压: -0.1~0.5Mpa

正负压: -0.1~0.9Mpa

正负压: -0.1~1.5Mpa

正负压: -0.1~2.4Mpa

过程连接：

螺纹

接液材质：

铜合金

304

外壳材质：

碳钢

304(L)

防护等级：

IP54
