All >> Level measurement >> Guided Wave Radar Level Transmitter

5300 Guided Wave Radar Level Transmitter - Processelite

*Picture for reference only !

Product name:

Guided Wave Radar Level Transmitter

Product series:

5300

Product brand:

Emerson/Emerson

Product feature:

• Communication protocols: 4-20 mA/HART®, Foundation™ Fieldbus, Modbus® • Safety: SIL 2 IEC 61508 certified, overfill protection tested by TÜV and WHG certified • Diagnostics: Enhanced diagnostic functions for predictive maintenance • Probe types: Rigid single lead, segmented single lead, flexible single lead, rigid twin lead, flexible twin lead, coaxial, PTFE-coated probes, steam probes • Warranty: Up to 5 years • Direct switch technology improves sensitivity and enhances availability

Favorite

Compare

Configure

Measuring principle:

Guided wave radar transmitter: Based on Time Domain Reflectometry (TDR) principle, it uses microwave pulses propagating along a metal rod or cable probe (waveguide) to measure level. When the pulse reaches the measured medium surface, it is partially reflected. The instrument precisely calculates the time difference between the transmitted and reflected pulses to determine the distance, which is then converted to level height. Its key advantage is the ability to reliably measure low dielectric constant media (such as liquefied gas, light oil), viscous liquids, levels under foam, or solid levels, with less influence from tank obstructions or vapor.

Product positioning:

Challenging applications

Using scenario:

The Rosemount 5300 level transmitter is suitable for challenging liquid, slurry, and solid measurements, providing outstanding reliability and safety in level and interface applications. The Rosemount 5300 offers many advantages such as easy installation and no calibration required, and is independent of process conditions. This radar is SIL 2 certified, making it your first choice for safety applications. Its rugged construction and built-in powerful diagnostic functions allow you to focus on what matters most—your plant.

防爆型式：

非防爆

Ex i

Ex d

最大量程：

杆式: 10m

同轴: 6m

精度：

±3mm

最高过程温度：

≤400℃

最大过程压力：

≤34.5MPa

通讯方式：

4~20mA

4~20mA HART

Modbus

过程连接：

螺纹

法兰

防护等级：

IP66

IP67

供电电源：

24V DC

人机界面：

无显示&不可操作

有显示&可操作

SIL认证：

SIL2 (单表)

SIL3 (双表)

All

Instruction

Operation

2D/3D

Certificate

Summary

产品认证5300.pdf

产品认证5300液位变送器.pdf

快速安装指南5300分段式导波杆安装说明书.pdf

快速安装指南5300液位变送器.pdf

5300 产品说明.pdf
